Forma™ 3960 Series Environmental Chamber, 821.2 L, SS, 200-230V, 50/60 Hz
- True laminar airflow through side plenums for extremely tight temperature uniformity
- Sophisticated microprocessor controls for constant display of temperature
- Alphanumeric message center for ease of setup and programming
- Access ports, locking casters and alarm contacts
- Capacity: 29 cu. ft. (821.2L) for high volumes and a broad range of products
- Operating temperature range: 5°C above ambient to 60°C (140°F)
Airflow System:
- Directed airflow system promotes an ideal growth environment.
- Positive pressure feed plenum and negative pressure return plenum direct air across surface of each solid shelf.
- Feed plenum cannot be blocked by chamber contents.
Intuitive, Powerful Enviro-Scan™ Control:
- Unit offers precise control without complicated programming.
- Operating modes include Run, Setpoint, Calibration and System Configuration.
- Easy-to-read display offers convenient, continuous monitoring.
- Audible/visual under- and over-temperature alarms offer peace of mind.
- Data outputs allow connection to in-house monitor/alarm system to track chamber conditions.
Durable Construction:
- Exterior cabinet: 18-gauge. cold-rolled steel, powder coated for durability; resists scratches and chipping.
- Heated glass door for minimal condensation and a clear view
- 2? (5.1cm) thick fiberglass cabinet insulation for maximum product thermal protection
- Solid, stainless-steel interior for long life and minimized equipment costs
- Five heavy-duty, solid stainless-steel shelves, adjustable on 2? (5.1cm) centers
- Swivel locking casters for easy mobility
- Leveling feet provide stability and added safety
- Thru-wall access ports on right and left chamber sides for probes, sensors, etc.
- Interior GFCI duplex receptacle on 115V Model (single European 230V CEE 7 on 230V Model) for shakers, cell rollers, and other equipment
- Exterior receptacle on upper-right side of control panel for connecting optional recorder or other equipment
Ordering Information:
Reinforced floor/shelf components are available for shakers, cell rollers, or other heavy equipment or product loads inside chamber. Units also available with chart recorders.
| Specifications | |
|---|---|
| Amperage | 5 A |
| Capacity (Metric) Shelf | 13.6 kg |
| Capacity (English) Shelf | 30 lb. |
| Certifications/Compliance | UL listed |
| Depth (English) Interior | 27 in. |
| Depth (Metric) Interior | 68.8 cm |
| Capacity (Metric) | 821 L |
| Chamber Material | Stainless Steel (304) |
| Dimensions (L x W x H) | 33 x 38 x 80 in. (83.8 x 78.7 x 203.2 cm) |
| Temperature Range (Metric) | Ambient +5°C to 60°C |
| Material | Powder-coated Cold Rolled Steel |
| Door Style | Heated, triple pane, tempered glass exterior |
| Electrical Requirements | 200/230 V, 50/60 Hz |
| Frequency | 50/60 Hz |
| Height (English) | 80 in. |
| Height (English) Interior | 60 in. |
| Height (Metric) | 203.2 cm |
| Insulation | 2 in. (5.1cm) fiberglass |
| Length (English) | 33 in. |
| Length (English) Shelf | 25.8 in. |
| Length (Metric) | 83.8 cm |
| Length (Metric) Shelf | 65.5 cm |
| No. of Shelves | 5 supplied/26 max. |
| Ports | Two 2.4 in. (6.1cm) I.D., one on each side |
| Shipping Weight (Metric) | 299.4 kg |
| Shipping Weight (English) | 660 lb. |
| Temperature Control | Enviro-Scan Microprocessor |
| Temperature Sensitivity | ±0.1°C |
| Temperature Sensor | Precision thermistor (over temperature and control); independent thermostat (over temperature safety) |
| Temperature Uniformity | ±0.4° at 30°C (86°F); ±0.3° at 37°C (98.6°F); ±0.5° at 45°C (113°F) |
| Voltage | 200/230 V |
| Wattage | 150 w |
| Weight (English) | 500 lb. |
| Weight (Metric) | 226.8 kg |
| Width (English) | 38 in. |
| Width (English) Interior | 31 in. |
| Width (English) Shelf | 30.6 in. |
| Width (Metric) | 78.7 cm |
| Width (Metric) Interior | 78.7 cm |
| Width (Metric) Shelf | 77.7 cm |
| Lighting | No Lighting |
| Type | Environmental Chamber |
| Unit Size | Each |
| Voltage | 200/230 V, 50/60 Hz |
|---|
